RUIAN YONGYI MACHINERY CO.,LTD
RUIAN YONGYI MACHINERY CO.,LTD
 |
| Place of Origin: | ZHEJIANG,CHIAN |
| Brand Name: | YONGYI |
| Certification: | CE |
| Model Number: | YYASY-B |
| Minimum Order Quantity: | 1SET |
|---|---|
| Price: | 20000-50000USD |
| Packaging Details: | Use in stretch film package, or wooden pack |
| Delivery Time: | within 25days delivery |
| Payment Terms: | TT |
| Supply Ability: | 25sets/month |
| Dimensions(L*W*H): | 4.5x1.8x2.0m | Gross Power: | 115KW |
|---|---|---|---|
| Type: | Rotogravure Printing Machine | Plate Type: | Gravure |
| Usage: | Label Printer | Color & Page: | Multicolor |
| Automatic Grade: | Automatic | Drying Method: | Electric Heating And Steam Heating Or Oil Heating |
| After-Sales Service Provided: | Engineers Available To Service Machinery Overseas |
It is widely used in intaglio multi-color printing for all assortments of plastic film. aluminum foil,aluminium foil,roll paper,etc rolling material.automatic color rigester.shaftless cylinder stroke clamping,outside heating device,recycling hot wind to dry,wind cooling, waste exhausted,double-working polition machinery automatic operation ,manual changing roll,active transmission shaft is imported,major converter with stable tension.accurate color rigester,hign speed,high efficiency,reasonable design,rellable quality.
II. Features:
1.Printing color :1-8
2.Printing color groups can be increase or decrease according to customer's requirement, it can be finished on both sides of the disposable continuous printing
3.Unwinding and winding adopt double location flip structure,Don't stop picking the material
4.The host variable frequency motor
5.Unwinding and winding traction adopt magnetic powder brake
6.Unwinding and winding traction adopt torque motor control
7.Printing press roller, traction roller and scraper adopt pneumatic
8.Imposition scheme: gas cap imposition without shaft
9.Ink circulation system
10.Tinted system: manual or computer automatic tinted (as per customer’s requirement)
III. Main Technical Parameters:
| Model | ASY-600 | ASY-1000 | |
| Diameter of core | 76mm | 76mm | 76mm |
| Diameter of material | 600mm | 600mm | 600mm |
| Diameter of roll | 110-300mm | 110-300mm | 110-300mm |
| Pringting width | 600mm | 800mm | 1100mm |
| Precidion of overprint | ±0.15mm | ±0.15mm | ±0.15mm |
| Pringting speed | 50-110m/min | 50-110m/min | 50-110m/min |
| Overalldimensions | 4.5x1.8x2.0m | 4.5x2.0x2.0m | 4.5x2.2x2.0m |
| Total power | 115kw | 135kw | 145kw |
| Weight | 1800kg | 2900kg |
3300kg |
Contact Person: Miss. Coral
Tel: 008615869643212
