LFQ Series Computer Control Vertical Type film roll Slitting and Rewinder Machine

LFQ Series Computer Control Vertical Type film roll Slitting and Rewinder Machine

    • LFQ Series Computer Control Vertical Type film roll Slitting and Rewinder Machine
    • LFQ Series Computer Control Vertical Type film roll Slitting and Rewinder Machine
    • LFQ Series Computer Control Vertical Type film roll Slitting and Rewinder Machine
  • LFQ Series Computer Control Vertical Type film roll Slitting and Rewinder Machine

    Product Details:

    Place of Origin: film roll Slitting and Rewinder Machine made in China
    Brand Name: YONGYI's film roll Slitting and Rewinder Machine
    Certification: CE of film roll Slitting and Rewinder Machine
    Model Number: LFQ-700 film roll Slitting and Rewinder Machine

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: 6500USD
    Packaging Details: Use in stretch film package, or wooden rack
    Delivery Time: within 25days delivery
    Payment Terms: TT
    Supply Ability: 25sets/month
    Contact Now
    Detailed Product Description
    Rated Power: 2.7kw No-Load Rotational Speed: 180m/min
    Saw Blade Diameter: 600mm Max. Cutting Depth: 0-450gsm
    Application: Automtic Dimensions: 2000×1110×1400mm
    Weight: 1200kg Type: Film Roll Slitting And Rewinder Machine

    1. Application
    This machine is suitable for separating and cutting such various roll materials as BOPP, PET, CPP, CPE,

    PVC, aluminum foil and paper, etc. And can cut edge, separate and cut material according to different requirements

     during production.

    2.Feature
    2.1The machine is a kind of vertical separating and cutting machine, rolling and releasing can be in front of or at the

    back of the machine.
    2.2Independent master control screen, more flexible and even easier operation.
    2.3 Automatic deviation-rectifying of releasing, photoelectric eye is suitable for tracking the edge and color of transparent material.
    2.4 Releasing tension adopts magnetic powder clutch control.
    2.5 Rolling adopts magnetic clutch control.
    2.6 Automatic slitter edge blowing-inhaling device.
    2.7 Automatic meter counting of material moving length.

    3.Main technical specification



    Model

    LFQ-700

    LFQ-1100

    LFQ-1300

    Max. Unwind width

    700mm

    1100mm

    1300mm

    Max. Unwind diameter

    Φ600mm

    Φ600mm

    Φ600mm

    Slitting width

    30-600mm

    30-600mm

    30-600mm

    Slitting speed

    5-160m/min

    5-160m/min

    5-160m/min

    Error

    <±0.5mm

    <±0.5mm

    <±0.5mm

    Total power

    2.7kw

    3.5kw

    3.5kw

    Weight

    1200kg

    1500kg

    1800kg

    Dimension

    2000×1110×1400mm

    2400×1110×1400mm

    2600×1110×1400mm

    LFQ Series Computer Control Vertical Type film roll Slitting and Rewinder Machine

    LFQ Series Computer Control Vertical Type film roll Slitting and Rewinder Machine

    LFQ Series Computer Control Vertical Type film roll Slitting and Rewinder Machine



    Material pathway diagram



    LFQ Series Computer Control Vertical Type film roll Slitting and Rewinder Machine

    Contact US:

    Sale Manager: Coral lau

    Email: coral@yongyijx.alimails.com

    Skype: buainesscoral

    Msn: businesscoral2012@hotmail.com

    Tel:008615869643212
